Product characteristics:
ยทRadial/axes and side mixing
ยทTouch screen PLC control
ยทTank rot-able
ยทShort mixing time
ยทSufficient mixing
ยทLarge volume, easy cleaning
ยทHigh automatics
| Model | 400L | 600L | 1000L | 2000L | 4000L |
| Main Motor(kW) | 1.5 | 2.2 | 4 | 5.5 | 11 |
| Mixing Power(kW) | 1.5 | 1.5 | 4 | 5.5 | 7.5 |
| Rotation Speed(RPM) | 7 | 7 | 7 | 7 | 7 |
| Mixing Shaft Speed (RPM) | 84 | 84 | 84 | 84 | 84 |
| Feeding port sizeย A1๏ผMM๏ผ | ฮฆ420 | ฮฆ420 | ฮฆ420 | ฮฆ420 | ฮฆ650 |
| Discharging port sizeย A2๏ผMM๏ผ | ฮฆ200 | ฮฆ200 | ฮฆ250 | ฮฆ250 | ฮฆ250 |
| Rotation diameterย B1๏ผMM) | 1900 | 2000 | 2500 | 2800 | 3080 |
| Height of discharge outletย H1๏ผMM๏ผ | 650 | 650 | 650 | 650 | 700 |
| Weight (KG) | 500 | 700 | 1000 | 1800 | 2500 |
| Overall dimensionsย LรWรH(MM) | 1800*800*1700 | 2200*1000*1700 | 2700*1500*2500 | 3100*1600*2600 | 3800*2200*3100 |
